Thermal Stencil Printer - A3 / A4 - Black

The KW Thermal Stencil Printer creates tattoo stencils from printed designs using thermal transfer. It produces copies in A3 format as well as smaller sizes such as A4, covering a range of design sizes from a single unit.

The printer uses microprocessor control and a built-in temperature sensor that regulates both the lamp and the cooling-down process. Two status LEDs, one green and one red, indicate the state of the device, while two relays work together to control operation. Dual fans and automatic overheat protection help keep the unit running safely during repeated use, and the metal housing provides a durable, easy-to-clean build for studio environments.

Please note: A laser printer is required to produce stencils. Prints made with inkjet printers will not transfer correctly.

Key Features:

• Thermal stencil printer for A3 and A4 designs
• Microprocessor-controlled operation for consistent printing and heat regulation
• Built-in temperature sensor regulating the lamp and cooling-down process
• Green and red status LEDs to show device status at a glance
• Dual fans with automatic overheat protection
• Durable metal housing
• CE marked

Technical Specifications:

• Maximum Stencil Size: 290 x 410 mm
• Recommended Carrier Size: 300 x 430 mm
• Power Consumption: 1700W
• Nominal Voltage: 230V / 50Hz
• Nominal Current: 6A
• Internal Lamp Fuse (lamp only): 10A
• Outlet Fuse Fuse for Electrical Outlet: 16A
• Material: Metal
• Dimensions (WxDxH): 520 x 200 x 115 mm
• Weight: 6.5 kg
